Synonyms: Silicon wafer (single side polished) <100>, P-type, diam. x thickness 1 in. x 300-400 μm
Silicon wafers or a “slice” of substrate find applications in the fabrication of integrated circuits, solar cells etc. They serve as a substrate for various microelectronic devices.
S 8044 (OTTO) Silicon wafer, single side polished, <100>, N-type, diam. x thickness 1 in. x 300-400 μm - used in electronics for the fabrication of integrated circuits and in photovoltaics for conventional, wafer-based solar cells.
WGK Germany 2
Certificate Of Analysis
(For eg. B 1615-0108)
Other Documents
