Silicon wafer, <100>, P-type, contains boron as dopant, diam. × thickness 2 in x 250 μm

Code: S 6091

PRIME

Si

9002

Double side polished

28.09

Bottle / Drum
18%

PRIME

Si

9002

Double side polished

28.09

Bottle / Drum

18%
PackingsPrice (INR)
1 pc 18099.00
10 pc POR
Custom size POR
Packings
Enquire
Properties
2 inch

± 1%

250 μm

± 1%

Double side polished

P-type

(100)

± 0.5°

1-5 ohm.cm or less

Boron as dopant

Less than equal to 60 µm

Less than equal to 60 µm

< 5Å

Description

Silicon wafers or a “slice” of substrate find applications in the fabrication of integrated circuits, solar cells etc. They serve as a substrate for various microelectronic devices.

Application

S 6091 (OTTO) Silicon wafer, <100>, P-type, contains boron as dopant, diam. × thickness 2 in x 250 μm - used in electronics for the fabrication of integrated circuits and in photovoltaics for conventional, wafer-based solar cells.

Safety Information

WGK Germany 2

Documentation

Certificate Of Analysis

(For eg. B 1615-0108)

Other Documents

For any quries, please write to us at

qc@ottokemi.com
Technical Services

Our team of R&D Experts and Scientists have expertise in all areas of research of Lab Chemicals, Nano Technology, Life Science, Custom Synthesis, Chromatography, and many others.

Enquire Now

DisclaimerThe above particulars do not release the customer from the obligation to carry out an inspection of goods received.
Not for medical, household or any other uses, for lab use only, Please test before use.
