Plano Convex Spherical Lens, Dia 50.8mm, Focal Length 100mm

Code: PCSL111
Bottle / Drum
18%

Bottle / Drum

18%
PackingsPrice (INR)
1 pc POR
100 pc POR
1000 pc POR
Packings
Enquire
Properties
NBK7 / BK-7 / Fused Silica

50.8 mm (+0.0, -0.4 mm)

100 mm

λ/4 at 633 nm or better over 85% of the diameter

3-4 mm

60-40 Scratch-Dig

≤ 3 arc minute

± 3% or better

0.25 mm x 45o or nearest standard

Uncoated

Description

Plano-convex lens are used to focus a collimated beam, produces a sharper focal spot when used with the convex side towards the beam source.

Application

Plano-convex lenses are positive focal length elements that have one spherical surface and one flat surface. These lenses are designed for infinite conjugate (parallel light) use or simple imaging in non-critical applications. These optic lenses are ideal for all-purpose focusing elements.
