Silicon sputtering target, diam. × thickness 2 inch × 3 mm, 99.999%

Code: S 3155

Si

28046900

28.09

Bottle / Drum
18%

Si

28046900

28.09

Bottle / Drum

18%
PackingsPrice (INR)
1 pc POR
10 pc POR
100 pc POR
Packings
Enquire
Properties
99.999%

Solid

2 inch

± 5%

3 mm

± 1%

Description

Silicon wafers or a “slice” of substrate find applications in the fabrication of integrated circuits, solar cells etc. They serve as a substrate for various microelectronic devices.

Application

S 3155 (OTTO) Silicon sputtering target, diam. × thickness 2 inch × 3 mm, 99.999% - used for the production of the silicon, sputtering is widely used to produce a back reflector layer (made predominantly with aluminum) and front contacts (made with transparent conducting oxides, TCO).
