Silicon wafers or a “slice” of substrate find applications in the fabrication of integrated circuits, solar cells etc. They serve as a substrate for various microelectronic devices.
SSC 561 (OTTO) Silicon wafer (single side polished), <111>, N-type, contains phosphorus as dopant, diam. x thickness 2 in. x 0.275 mm - used in electronics for the fabrication of integrated circuits and in photovoltaics for conventional, wafer-based solar cells.
WGK Germany 2
Certificate Of Analysis
(For eg. B 1615-0108)
Other Documents
For any quries, please write to us at
7789-24-4
Lithium fluoride, optical windows, 40 mm dia, 15 mm thick (with Al coated on one face for working wavelength 1550nm)
7440-21-3
Silicon substrate (single side polished), <100>, P-type, diam. × thickness 1 in. × 300 - 400 μm
Fused silica wafers dia 100 mm thick 0.5 mm
Dielectric Beam Splitter, dia 100 mm, thick 15 mm
