Silicon wafers or a “slice” of substrate find applications in the fabrication of integrated circuits, solar cells etc. They serve as a substrate for various microelectronic devices.
SSC 855 - Silicon wafer (single side polished), <111>, P-type, contains boron as dopant, diam. × thickness 2 in. x 0.5 mm - used in electronics for the fabrication of integrated circuits and in photovoltaics for conventional, wafer-based solar cells.
