Specification Sheet

Single crystal sapphire substrates L × W × thickness 25 mm × 25 mm × 0.5 mm

: SSCS 0090

: Single crystal sapphire has a unique combination of physical, chemical and optical properties allowing it to withstand high temperatures, high pressure, thermal shock, and water or sand erosion

: sapphire substrates - are usually used for hybrid microelectronic applications requiring a uniform dielectric constant and highly insulating characteristics. Sapphire substrates for photoelectronic applications, including the high brightness LED market.


Properties

: 99.99%+

: C-axis (0001)

: ± 0.1º

: 25 mm x 25 mm

: 0.5 mm

: ± 5%

: 5 μm or nearest standard

: Both surfaces epi-polished with r.m.s surface roughness ≤ 5 Å


Safety Information

WGK Germany 2
RTECS VW0400000


PackingsPrice (INR)
1 pc POR
10 pc POR
Custom size POR
