LBO crystals, Frequency conversion (SHG OF 1064nm TO 532nm in Y-Z plane)

: LBOC001

: Lithium triborate (LiB3O5) LBO is a non-linear optics crystal. It has a wide transparency range, moderately high nonlinear coupling, high damage threshold and desirable chemical and mechanical properties.

: Lithium triborate (LBO) crystals are applicable in various nonlinear optical applications.

Properties

: Crystal optics,LBO Optics Crystal

: SHG OF 1064nm TO 532nm in Y-Z plane

: DBAR @ 1064/532 nm, R<0.05% @ 1064 nm & R<0.2% @ 532 nm

: 6 x 6 x 18

: Type II, CPM, Ø-21.1°, Ø-90° at 20°C

: <0.03%cm-1 @ 1064nm

: Less than λ /8 @ 633nm

: =>10/5 Scratch/dig per MIL-0-13830A

: No visible scattering paths or centers when inspected by a 30 mW green laser

: >= λ / 8 @ 633nm

: better than 20 arc seconds

: better than 5 arc minutes

: △0 < ± 0.5° △0 < ± 0.5°

: (W ± 0.1mm) x (H ± 0.1mm) x (L + 0.2mm / -0.1mm)

: >= Central 90% of total area

: >= 10 GW/cm2 @ 1064 nm, 10ns, 10Hz

: > 1GW/cm2 for 1.064 μm, 10ns, 10Hz

: > 0.5GW/cm2 for 0.532 μm, 10ns, 10Hz

Safety Information

WGK Germany 1

PackingsPrice (INR)
1 pc POR
5 pc POR
Custom size POR
