Specification Sheet

β Barium borate single crystal (10 x 10 x 0.3 mm)

Synonyms

: BBO Crystals

Code

: BBO 090

Description

: Beta barium borate (BBO) crystals are nonlinear optical crystal, used as laser crystals, NOPA crystals or non collinear phase matching.

Applications

: Application Second harmonic generation @ 800 nm

Properties

Categories

: Crystal optics,β-Barium Borate Single Crystal

Material

: BBO crystal

Dimensions (x × y)

: 10 x 10 mm

Thickness

: 0.3 mm

Clear aperture

: ≥ 90%

Clarity

: No visible scattering paths or centers when inspected by a low power (~50mW) green laser

Chamfer

: ≤ 0.2 mm × 45°

Chip

: ≤ 0.1mm

Phase matching

: Type 1

Orientation Theta

: 29.2°

Orientation Phi

: 90°

Cut angle orientation accuracy

: ≤15 arc min (or 0.25 degrees)

Wavefront distortion

: ≤ λ/8 @ 633 nm

Flatness

: ≤ λ/8 @ 633 nm

Parallelism

: ≤ 20 arc seconds

Perpendicularity

: ≤ 5 arc min

Anti-reflection coatings

: Both side AR

Coating wavelengths

: 400 and 800 nm

Surface quality (S-D)

: better than 10/5

Safety Information

Safety Information for this product is unavailable at this time.

Packings	Price (INR)
1 pc	POR
5 pc	POR
