Dielectric Beam Splitter, dia 100 mm, thick 15 mm

Code: DBS 9639
9001 / 9002
18%
9001 / 9002
18%
PackingsPrice (INR)
1 pc 160299.00
10 pc POR
Packings
Dielectric Beam Splitter, dia 100 mm, thick 15 mm, DBS 9639, (1)
Enquire
Captcha
Properties
Crystal optics,Dielectric mirror
Laser grade BK7 glass
100 mm
± 1 mm
15 mm
± 1 mm
50/50
400 nm - 700 nm
λ/10 (at λ=589.6 nm), over 90% surface area
≤ 30" (± 2') arc minutes
road-band (400 nm – 700 nm) dielectric beam splitter coating
broad-band (400 nm – 700 nm) AR coating R <0.5%
Safety Information

WGK Germany -

RTECS MD5070000

Documentation

Certificate Of Analysis

(For eg. B 1615-0108)
