Silicon substrate (single side polished), <100>, P-type, diam. × thickness 2 in. × 300 - 400 μm

Code: SS 405

Si

9001

28.09

Bottle / Drum
18%

Si

9001

28.09

Bottle / Drum

18%
PackingsPrice (INR)
1 pc POR
10 pc POR
1000 pcs POR
Packings
Enquire
Properties
<100> ± 0.5 °

2” (50.8±0.2 mm)

300 - 400 μm

± 5% approx

One side polished

Ra < 5 Å

1- 10 ohm-cm

Description

Silicon wafers or a “slice” of substrate find applications in the fabrication of integrated circuits, solar cells etc. They serve as a substrate for various microelectronic devices.

Application

SS 405 (OTTO) Silicon substrate (single side polished), <100>, P-type, diam. × thickness 1 in. × 300 - 400 μm - used in electronics for the fabrication of integrated circuits and in photovoltaics for conventional, wafer-based solar cells.
