Synonyms: Silicon substrate, single crystal, dia 3 in, thickness 100 μm
Silicon wafers or a “slice” of substrate find applications in the fabrication of integrated circuits, solar cells etc. They serve as a substrate for various microelectronic devices.
SW 207 (OTTO) Silicon wafer, single crystal, dia x thickness 3 in x 0.1 mm - used in electronics for the fabrication of integrated circuits and in photovoltaics for conventional, wafer-based solar cells.
WGK Germany 2
Certificate Of Analysis
(For eg. B 1615-0108)
Other Documents
