Silicon wafers or a “slice” of substrate find applications in the fabrication of integrated circuits, solar cells etc. They serve as a substrate for various microelectronic devices.
S 6075 (OTTO) Silicon wafer, <100>, P-type, contains boron as dopant, diam. × thickness 4 in x 525 μm - used in electronics for the fabrication of integrated circuits and in photovoltaics for conventional, wafer-based solar cells.
WGK Germany 2
Certificate Of Analysis
(For eg. B 1615-0108)
