Fused silica optical window, 177 mm dia, 10 mm thick

Code: FS 4050
9001
Container
18%
9001
Container
18%
PackingsPrice (INR)
1 pc POR
10 pc POR
100 pcs POR
Packings
Fused silica optical window, 177 mm dia, 10 mm thick, FS 4050, (1)
Enquire
Captcha
Properties
Crystal optics,Chemically coated windows / substrates
Fused silica
Both faces optically polished to λ/4
< 5'
High Damage Threshold broadband dielectric AR coating (R< 1% ) for 800nm +/- 50nm
0.5 x 45 deg
177 mm
± 5%
10 mm
± 5%
Application

FS 4050 (OTTO) Fused silica optical window, 177 mm dia, 10 mm thick - used widely for Laser optics, optical grade UV Fused Silica windows and lenses, mirror blanks and substrates, wedges, optical beamsplitters and filters, prisms, lightpipes, space and aircraft windows, solar cells, high quality coating substrates etc.

Safety Information

Safety Information for this product is unavailable at this time.

Documentation

Certificate Of Analysis

(For eg. B 1615-0108)

Other Documents

For any quries, please write to us at

qc@ottokemi.com
