Broadband Non-Polarizing Cube Beam Splitters (25 mm x 25 mm x 25 mm)

Code: BPCB258
9001
18%
9001
18%
PackingsPrice (INR)
1 pc POR
10 pc POR
50 pc POR
Packings
Broadband Non-Polarizing Cube Beam Splitters (25 mm x 25 mm x 25 mm), BPCB258, (1)
Enquire
Captcha
Properties
Crystal optics,Broadband non-polarizing cube beam splitters
NBK7 / BK7
>95% of dimension
25 mm x 25 mm x 25 mm
±0.25 mm
Visible, 400 nm - 700 nm
Broadband (400 nm - 700 nm), Multilayer coating on all entrance and exit faces, Ravg <0.5% per surface. Unused surfaces finely grounded. No cementing defects.
0.25 mm × 45° or nearest standard (all edges)
λ/4 at 632.8 nm per 25mm range
Linear
45% (±5%)
45% (±5%)
±3 arc min
90° ±3 arc min
0° ±5°
-50 °C - 90 °C
>500mJ/cm2, 20ns, 20Hz, @1064nm
60-40 scratch-dig
Safety Information

Safety Information for this product is unavailable at this time.

Documentation

Certificate Of Analysis

(For eg. B 1615-0108)

Other Documents
