β Barium borate crystals (15 x 15 x 5 mm3)

Code: BBO 144

Synonyms: BBO Crystals

9002
Container
18%
9002
Container
18%
PackingsPrice (INR)
1 pc 405099.00
5 pc POR
Packings
β Barium borate crystals (15 x 15 x 5 mm3), BBO 144, (1)
Enquire
Captcha
Properties
Crystal optics,β-Barium Borate Single Crystal
BBO crystal
15 x 15 x 5 mm3
± 5%
90% or larger
Type 1 SHG @ 1054 nm
≤ λ/8 at 633nm
≤ λ/8 at 633nm
10-05
Surface 1 AR coated at 1054 nm and Surface 2
AR coated for 1054 and 527 nm with R<0.5 %.
≥ 0.5 GW/cm2 for 10 ns pulses @ 1064 nm
The crystals should be mounted in an appropriate black anodized holder
Description

Beta barium borate (BBO) crystals are nonlinear optical crystal, used as laser crystals, NOPA crystals or non collinear phase matching.

Application

Application Second harmonic generation of 1054 nm

Safety Information

Safety Information for this product is unavailable at this time.

Documentation

Certificate Of Analysis

(For eg. B 1615-0108)

Other Documents
